FULLY
AUTOMATIC 8-LANE VERTICAL, FORM, FILL & SEAL MACHINE
Model- NP-600, NP-800, NP-1000, |
|
SPECIFICATIONS
: |
|
|
Speed : |
Upto 70 Strock Per
minute Per Track (depending upto the products & Quantity to be
filled. |
|
Bag Shape &
Sealing : |
Different Profiles like Bottle neck,
and easy pour etc. |
|
No. of Track : |
Depending upon the width of the pouch. |
|
Max. roll width : |
300mm to 1200mm |
|
Max. roll dia : |
450mm |
|
Roll core dia : |
450mm/ 76mm |
|
Max. lenth of pouch : |
150mm |
|
Packing limit : |
2gms to 1000gms |
|
Main motor : |
2.2KW, 3-phase, 415 volts AC |
|
Power Consumption : |
9.5KW |
|
Machine dimension : |
2100x1350x1900mm |
|
New weight : |
2200kgs |
|
Gross weight : |
2500kg |
|
Machine colour : |
off white/ siemens grey, smoke gray |
|
Packing material : |
available in the market, heat
sealable, LLDPE, LDPE metalise poly & laminations films. |
|
Products to be Packed: |
shampoo, oil, cream,
ketch-up, power, granules, liquor etc. |
|
Vertical & horizontal : |
mechanically driven dealing |
|
Sealing jaw drive : |
mechanical cam |
|
Batch cutting : |
pneumatic |
|
Film cutting : |
fully automatic |
|
Control panel : |
air-cooled with all applicable
standard parts Packing box size |
|
 |
